Detail Information |
|||
| Warranty: | 2 Years | Engine: | V6 |
|---|---|---|---|
| Chassis: | 4×2 | Drive System: | 2WD Or 4WD |
| Size: | Large | Manufacturer: | CXFIRE |
| Model: | SG40 | Product Name: | Fire Fighting Truck |
| High Light: |
V6 Fire Fighting Truck, 2WD Fire Fighting Truck, 4000L Tank Fire Truck |
||
Product Description
Product Description:
The SAIC-Iveco Hongyan 4000L Water/Foam Fire Truck is specially designed to serve the cities. It is outfitted with a 3000L water tank and a 1000L foam water tank, while comfortably accommodating up to 8 firemen. With a powerful water pump, the fire truck is capable of producing a flow rate of 60L/s. This fire truck is also equipped with a fire monitor, with a range of up to 60m.
In addition to these abilities, the fire truck is also configured with some amazing features:
- 3000L water tank
- 1000L foam water tank
- 80L/s flow rate fire pump
- Fire monitor with a range of 60m
Features:
This SAIC-IVECO HONGYAN vehicle is optional with 4×2 wheelbase configuration. It gets an inline 6-cylinder, turbocharged, inter-cooled diesel engine and a manual gearbox. The rated power is 221Kw and it has full power sandwich type PTO. With a 200L aluminum alloy fuel tank, you have enough fuel for long distance travel.
Technical Parameters:
Fire Monitor
The fire monitor is an important part of firefighting system, with a rated flow of at least 48 liters per second. It’s capable of sending water or foam to a distance of up to 60 meters or 55 meters respectively. In terms of positioning and control, the monitor can be installed at the top of the carriage, and can be manually controlled with a 360 degree horizontal rotation, alongside a 15 to 60 degree pitch and rotation.
Fire Pump
The fire pump is another crucial element in the fire-fighting system. With a rated pressure of 10 bar, and a rated flow of 60 liters per second, it also comes with an electric vacuum pump and a wiper water diversion. The fire pump can suck in water from a depth of up to 7 meters within a maximum time of 50 seconds. To ensure superior performance, the fire pump is typically installed in the rear pump room.
Applications:
Fire trucks are primarily utilized by municipal and petrochemical fire stations, owing to their size and versatility. These vehicles are characterized by their excellent maneuverability and capability in making effective responses to emergencies.
Fire brigades are one of the most salient user of these vehicles, as they take advantage of the robustness, maneuverability, and reliability that fire trucks offer.
Customization:
Brand Name: CXFIRE
Model Number: SG40
Place of Origin: China
Certification: CCC
Minimum Order Quantity: 1
Price: USD150,000
Packaging Details: Standard Export Package
Delivery Time: 5 months
Payment Terms: T/T, L/C
Supply Ability: 1000 Units Per Year
Max Speed: 90km/h
Size: Large
Drive System: 2WD Or 4WD
Product Name: Fire Fighting Truck
Model: SG40
CXFIRE’s Fire Fighting Truck SG40 is the perfect solution for fire emergency, response and rescue. It is capable of reaching a maximum speed of 90km/h and it comes with either 2WD or 4WD drive system. This fire truck is made with a large size and it is certified with CCC. The minimum order quantity is 1 unit and the price is USD150,000. The delivery time is 5 months and the supply ability is 1000 units per year. The package is a standard export package and the payment terms are T/T and L/C.
Support and Services:
Fire Fighting Truck provides technical support and services for customers. Our qualified staff are available to assist customers in resolving any technical issues they might experience with the product. We also offer a variety of services such as on-site maintenance, installation, and training. We provide prompt and effective solutions to ensure customer satisfaction.
Packing and Shipping:
Fire Fighting Truck requires careful packaging and shipping. The following procedures should be followed to ensure that the product arrives safely and in good condition:
- The fire fighting truck should be placed in an appropriately sized carton.
- The carton should be reinforced with suitable packing material.
- The carton should be sealed securely.
- The carton should be labeled clearly with the destination address.
- The carton should be shipped via a reliable carrier.
